Building Interactive Streaming Apps: WebRTC, WHIP & WHEP Explained

Live streaming has become extremely popular, especially for broadcasting live sports and streaming on platforms like YouTube and Twitch. Today, it’s easy to watch major events online, and that’s starting to take over from traditional forms like watching on TV.

The vast majority of streaming platforms use a technology called HTTP Adaptive Streaming (HAS), which enables delivering video to millions of viewers with only a few seconds of latency. But if you want truly real-time, interactive experience, there are a few things to consider.

Going beyond traditional TV — WebRTC for new applications

If you’re trying to move past the limitations of traditional TV and build something better — with significantly less delay — or if you want to use live streaming in totally new ways, there are plenty of options to consider. Just think about creators being able to interact with the audience in real time, or people joining an online auction and actually participating as it happens.

Protocols like HLS (HTTP Live Streaming) or DASH (Dynamic Adaptive Streaming over HTTP) are ideal for video-on-demand or mass broadcasts. However, when low latency streaming is critical and when you can’t afford a delay of even one second, HLS and DASH typically can’t keep up.

Fortunately, there is the WebRTC standard, which is perfectly suited for applications that require ultra-low latency and almost perfect synchronization.

What is WebRTC and why does it matter?

WebRTC was designed for direct communication with very low latency — around 200 milliseconds — allowing natural interactions between participants. The standard is supported by browsers, which simplifies the integration of WebRTC-based solutions.

It’s worth keeping in mind that achieving such low latency makes WebRTC a complex solution that incorporates many different protocols such as ICE, TURN, STUN, DTLS, SDP, and many others. This, in turn, often translates into troublesome implementation, debugging, and usage.

Plus, WebRTC doesn’t actually specify how connections are established — so, theoretically, they could even involve carrier pigeons. As a result, each implementation of a WebRTC-based solution varies, which adds complexity and means each streaming server needs its own approach to setting up connections.

WHIP & WHEP protocols — simplifying WebRTC for broadcasting

In broadcasting scenarios, the connection establishment has been standardized by the WHIP and WHEP protocols, which clearly define how the process should work. These protocols rely on the HTTP protocol and strictly specify the sequence of messages sent to establish connections, making the process easier.

WHIP (WebRTC-HTTP ingestion protocol) focuses on stream ingestion, allowing broadcasters to send live media to WebRTC-compatible servers by leveraging HTTP(S) for signaling. This simplifies the setup for sending live streams over the internet.

On the other end, WHEP (WebRTC-HTTP egress protocol) deals with the distribution aspect, enabling straightforward delivery of live streams from WebRTC servers to the end-users. This helps reduce latency and improve quality of service by keeping the streaming experience stable and consistent.

By leveraging WHIP and WHEP, you can use the same implementation, applications, or players to receive streams from different providers. This standardization eliminates the need for custom solutions for each provider, lowering development costs and technical barriers for both broadcasters and content creators. As a result, these protocols offer a streamlined framework for efficiently managing the entire live streaming lifecycle — from broadcast to viewer.

Building a live streaming app: should you create your own infrastructure or use third-party providers?

When creating a streaming product, you have to decide whether to build your own infrastructure or rely on an external provider. Setting up and maintaining your own system can be complex and expensive, so many choose to go with third-party providers instead.

However, if you decide to build your own infrastructure, the first challenge is dealing with the WebRTC standard, which can be quite complex when it comes to transmitting multimedia. You basically have two options here:

Implementing the standard yourself, which gives you full control over the library and its features. However, this scenario requires having a dedicated and skilled team for implementation and maintenance.
Using an existing library and building a multimedia server based on it. Although this is a simpler scenario, it still requires a skilled team capable of effectively debugging WebRTC. And that’s often quite challenging.

Once your multimedia server is up and running, new challenges pop up — like keeping the quality high, scaling smoothly, and keeping latency low. This means managing geolocation, routing streams across clusters and instances, scaling your multimedia servers properly, and handling all the usual headaches of running a distributed infrastructure.

Sounds complex? Well, because it is. But external providers can take these burdens off your shoulders by delivering reliable, high-quality multimedia services and offering tools that make it easier to integrate WebRTC into your custom apps.

WebRTC for broadcasting made simple with Fishjam

One of the tools that makes live streaming and broadcasting easier is Fishjam. It’s a live-streaming and video conferencing API designed to seamlessly integrate WebRTC into your application, removing the complexity of custom WebRTC implementations and the need for deep multimedia expertise.

With ready-to-use React and React Native SDKs, adding live streaming to your app is simple and user-friendly. Plus, thanks to integration with tools like Smelter, it offers much more than just basic streaming.

To sum up, Fishjam lets you skip the hard parts and start building fast. Don’t wait, check the website, and be sure to give it a try! And if you need help along the way, feel free to reach out to us at projects@swmansion.com.

Want to learn more about Fishjam and its capabilities? Check our video:

To explore other applications of WebRTC, read our article on Real-Time Gesture Recognition!
